Description

Range of axial extractors with airflow rates of 175 m³/h, for connection to 120 mm diameter circular ducting.

Motor mounted on silent-elastic-blocks which absorb the vibrations and allow offering very low noise level.

All the fans are manufactured from injection moulded plastic, fitted with automatic shutter and single phase 230V-50Hz, class B low consumption motor equipped with thermal overload protection.

All the fans are class II insulation, IP45 rated and suitable to operate with air temperature up to 40ºC.

The built-in timer allows for a delay in switching off, with an adjustable range of 1–30 minutes.

Electrical connection: 230 V/50 Hz

Maximum airflow: 175m3/h

Maximum volume: 35dB

Installation instructions:
https://www.youtube.com/watch?v=T847jYV4pPw
